Diesel Mobile Compressor Two Stage - SEIZE AIR Compressor

Permanent magnet variable frequency single-stage screw air compressor

Diesel Mobile Compressor Two Stage（SDPT Series）

IE4 Premium Efficiency（IE5 Optional）, Low-Noise,PM Motor(IP65),Dual VSD

	Power	18-492kW
	Air outflow	12-43m³/min
	Max pressure	8-25bar

Product Parameter

分页表格

SDP-12/18T~SDPS-43/25T

Model	Capacity		Working Pressure		Engine	Weight （kg）	Dimensions mm	Compressed Air Outlet	Weld QTY
Model	m3/min	Cfm	Bar	PSi	Engine	Weight （kg）	Dimensions mm	Compressed Air Outlet	Weld QTY
SDP-12/18T	12	420	18	260	YUCHAI 118kW	2000	3300x1900x1900	G1.1/41 x G3/41	2
SDP-15/18T	15	420	18	260	YUCHAI 162kW	2300	2900x1550x2280	G21 x G3/41 x	4
SDP-17/18T	17	595	18	260	YUCHAI 162kW	2400	2900x1550x2280	G21 x G3/41 x	4
SDP-17/18TC	17	595	18	260	Cummins 154kW	2400	2900x1550x2280	G21 x G3/41 x	4
SDP-13/25TC	13	455	25	365	Cummins 154kW	2400	2900x1550x2280	G21 x G3/41 x	4
SDP-19/18T	19	665	18	260	YUCHAI 191kW	3500	3200x1800x2380	G21 x G3/41 x	4
SDP-19/18TC	19	665	18	260	Cummins 194kW	3500	3200x1800x2380	G21 x G3/41 x	4
SDP-22/20T	22	770	20	290	YUCHAI 228kW	3600	3200x1800x2380	G21 x G3/41 x	4
SDP-23/23T	23	805	23	335	YUCHAI 250kW	4800	4100x1900x2900	G21 x G3/41 x	4
SDP-23/23TC	23	805	23	335	Cummins 264kW	4800	4100x1900x2900	G21 x G3/41 x	4
SDP-25/23TC	25	875	23	335	Cummins 264kW	4800	4100x1900x2900	G21 x G3/41 x	4
SDP-27/23T	27	945	23	335	YUCHAI 295kW	4900	4100x2000x2900	G21 x G3/41 x	4
SDP-29/23T	29	1015	23	335	YUCHAI 295kW	4900	4100x2000x2900	G21 x G3/41 x	4
SDPS-29/23T	29	1015	23	335	YUCHAI 295kW	4100	3600x2000x2300	G21 x G3/41 x	4
SDPS-31/25T	31	1085	25	365	YUCHAI 412kW	4500	3600x2000x2300	G21 x G3/41 x	4
SDPS-31/25TC	33	1155	25	365	Cummins 410kW	4500	3600x2000x2300	G21 x G3/41 x	4
SDP-33/25T	33	1155	25	365	YUCHAI 412kW	6600	4750x2200x2600	G21 x G3/41 x	4
SDP-33/25TC	33	1155	25	365	Cummins 410kW	6600	4750x2200x2600	G21 x G3/41 x	4
SDPS-36/30T	36	1260	30	435	YUCHAI 412kW	6000	3900x2200x2300	G21 x G3/41 x
SDPS-36/30TC	36	1260	30	435	Cummins 410kW	6000	3900x2200x2300	G21 x G3/41 x
SDPS-30/35T	30	1050	35	510	YUCHAI 412kW	6000	3900x2200x2300	G21 x G3/41 x
SDPS-30/35TC	30	1050	35	510	Cummins 410kW	6000	3900x2200x2300	G21 x G3/41 x
SDP-39/25TC	39	1365	25	365	Cummins 522kW	7000	4950x2200x2900	G21 x G3/41 x	4
SDPS-43/25T	43	1505	25	365	YUCHAI 492kW	7200	4200x2200x2300	G21 x G3/41 x
