Dry Oil-Free Screw Compressor | Single & Double Stage

Dry-oil-free-single-stagedouble-stage-screw-air-compressor-scaled

Oil Free Screw Air Compressor（SWT Series）

100% Oil-Free,TUV Class 0 Certificate

⚡	Power	37-450KW
💨	Air outflow	4.7-81 m³/min
⚙️	Max pressure	4.5-10.5bar

Core Components+ System Advantages

100% Oil-Free Air Compressor with Triple Sealing System & Smart IoT Control

Certified 100% Oil-Free Air
● Triple sealing system guarantees pure oil-free air (Class 0, ISO 8573-1)
● Zero risk of oil contamination
Ultra-Precision AGMA 13 Gearing
● High-precision gearbox (AGMA Class 13) ensures smooth power transmission
● Withstands extreme operating conditions (dust, humidity, temperature fluctuations)
Next-Gen Rotor Design for Maximum Efficiency
● Optimized rotor profile improves airflow efficiency by 12–15%
● Stainless steel rotor core + special alloy coating provides:
✓ Heat resistance (up to 300°C)
✓ Anti-wear & corrosion protection
✓ 50% longer lifespan vs standard rotors
Leak-Proof Gearbox Protection
● Oil mist separator on gearbox vent captures 99% of lubricant vapors
● U-shaped pressure differential valve prevents oil leaks
● Maintains clean operation environment
Dual-Stage Air Intake System
● Two-stage filtration (pre-filter + main filter) ensures:
✓ Optimal air intake quality
✓ 5–8% higher compressor efficiency
✓ Extended component life
Smart IoT Monitoring & Control
● Real-time performance tracking (pressure, temp, energy use)
● Predictive maintenance alerts via cloud connectivity
● Remote troubleshooting reduces downtime

Product Parameter

SWT-37A/W~SWT-75A/W

Model			SWT-37A/W		SWT-45A/W			SWT-55A/W			SWT-75A/W
Pessure(Bar)			7	8	7	8	10	7	8	10	7	8	10
Psig			102	116	102	116	145	102	116	145	102	116	145
Capacity(m/min)			5.60	5.60	6.50	6.50	5.50	8.50	8.40	6.50	12.60	12.60	10.30
Power(Kw)			37		45			55			75
Water Cooling	Outlet Pipe		DN50								DN80
	Weight(Kg)		2200		2300			2400			3000
	Dimension	L(mm)	2440								3200
		W(mm)	1700								1950
		H(mm)	1660								1810
Air Cooling	Outlet Pipe		DN50								DN50
	Weight(Kg)		2300		2400			2500			3100
	Dimension	L(mm)	3050								3450
		W(mm)	1700								1800
		H(mm)	1700								1850

SWT-90A/W~SWT-160A/W

Model			SWT-90A/W			SWT-110A/W			SWT-132A/W			SWT-160A/W
Pressure(Bar)			7	8	10	7	8	10	7	8	10	7	8	10
Psig			102	116	145	102	116	145	102	116	145	102	116	145
Capacity(m/min)			15.20	15.00	12.50	20.00	19.80	15.00	24.50	22.00	19.50	27.00	25.00	24.00
Power(Kw)			90			110			132			160
Water Cooling	Outlet Pipe		DN80			DN80		DN80	DN80			DN80
	Weight(Kg)		3200			3800		3400	3900			4000
	Dimension	L(mm)	3200			3350		3200	3350			3350
		W(mm)	1950			1900		1950	1900			1900
		H(mm)	1810			1900		1810	1900			1900
Air Cooling	Oulet Pipe		DN50			DN80		DN50	DN80			DN80
	Weight(Kg)		3300			4000		3500	4100			4200
	Dimension	L(mm)	3450			4250		3450	4250			4250
		W(mm)	1800			2060		1800	2060			2060
		H(mm)	1850			2150		1850	2150			2150

SWT-185A/W~SWT-250A/W

Model			SWT-185A/W			SWT-200A/W			SWT-250A/W
Pressure(Bar)			7	8	10	7	8	10	7	8	10
Psig			102	116	145	102	116	145	102	116	145
Capacity(m³/mim)			30.50	30.50	26.50	36.50	36.50	30.30	42.50	42.50	36.00
Power(Kw)			185			200			250
Water Cooling	Oulet Pipe		DN100		DN80	DN100			DN100
	WeightKg)		5200		4400	5350			5400
	Dimension	L(mm)	3680		3350	3680			3680
		W(mm)	2020		1900	2020			2020
		H(mm)	2350		1900	2350			2350
Air Cooling	Oulet Pipe		DN100		DN80	DN100			DN100
	Weight(Kg)		5700		4300	5900			6100
	Dimension	L(mm)	4550		4250	4550			4550
		W(mm)	2200		2060	2200			2200
		H(mm)	2300		2150	2300			2300

SWT-280W~SWT-450W

Model			SWT-280W			SWT-300W			SWT-355W			SWT-400W			SWT-450W
Pressure(Bar)			7	8	10	7	8	10	7	8	10	7	8	10	7	8	10
Psig			102	116	145	102	116	145	102	116	145	102	116	145	102	116	145
Capacity(m³min)			53.50	48.50	42.00	58.50	53.00	48.00	63.80	58.00	53.00	70.00	63.00	58.00	80.00	70.00	63.00
Power(Kw)			280			300			355			400			450
Water Cooling	OutletPipe		DN125		DN100	DN125			DN100		DN125	DN150		DN100	DN150
	WeightKg)		7400		5500	7600			8100		7800	8350		8000	8600
	Dimension	L(mm)	4450		3680	4450			4700		4450	4700		4450	4700
		W(mm)	2350		2020	2350			2500		2350	2500		2350	2500
		H(mm)	2350		2350	2350			2400		2350	2400		2350	2400

SWT-37AV/WV~SWT-75AV/WV

Model			SWT-37AV/WV					SWT-45AV/WV						SWT-55AV/WV						SWT-75AV/WV
Presure(Bar)			4.5	5.5	6.5	7.5	8.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5
Psig			65	80	94	109	123	65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152
Capaciy(m/min)			4.7~7.3	4.6-6.6	4.4~5.9	4.5-5.6	4.5~5.6	4.5-9.0	4.7~8.5	4.7~7.3	4.8-6.8	4.6-6.5	4.5~5.6	8.8-~11.0	8.2~10.2	4.7~9.4	4.4-8.8	4.6-8.4	4.8-6.8	8.8~16.0	8.4-14.0	8.4~14.0	9.0~12.8	9.0~12.8	8.2~10.3
Power(Kw)			37					45						55						75
Water Cooling	Oulet Pipe		DN50											DN80		DN50				DN80
	Weight(Kg)		2200					2300						2800		2400				3000
	Dimension	L(mm)	2440											3200		2440				3200
		W(mm)	1700											1950		1700				1950
		H(mm)	1660											1810		1660				1810
Air Cooling	Outlet Pipe		DN50											DN50		DN50				DN50
	Weight(Kg)		2300					2400						2900		2500				3100
	Dimension	L(mm)	3050											3450		2900				3450
		W(mm)	1700											1800		1700				1800
		H(mm)	1700											1850		1890				1850

SWT-90AV/WV~SWT-160AV/WV

Model			SWT-90AV/WV						SWT-110AVWV						SWT-132AV/WV						SWT-160AV/W
Presure(Bar)			4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5
Psig			65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152
Capaciy(m/min)			9.6~19.1	9.3~16.9	9.3~16.9	8.8~16.0	9.2~15.3	8.8~12.5	15.6~26.0	14.1~23.5	14.7~21.0	14.6~20.8	14.9~19.8	8.7~15.8	14.3~28.5	14.6-26.5	14.7~24.5	14.7~24.5	14.3~22.0	10.0-20.0	215-39.0	20.4~34.0	19.5~32.5	14.0~28.0	14.6~26.5	14.4~24.0
Power(Kw)			90						110						132						160
Water Cooling	Oulet Pipe		DN80						DN80					DN80	DN80						DN100			DN80
	Weight(Kg)		3000						3800					3400	3900						5150			4000
	Dimension	L(mm)	3200						3350					3200	3350						4100			3350
		W(mm)	1950						1900					1950	1900						2150			1900
		H(mm)	1810						1900					1810	1900						2250			1900
Air Cooling	Outlet Pipe		DN50						DN80					DN80	DN80						DN100			DN80
	Weight(Kg)		3300						4000					3500	4100						5300			4100
	Dimension	L(mm)	3450						4250					3450	4250						4550			4250
		W(mm)	1800						2000					1800	2060						2200			2000
		H(mm)	1850						2200					1850	2150						2300			2200

SWT-185AV/WV~SWT-250AV/WV

Model			SWT-185AV/WV						SWT-200AV/WV						SWT-220AV/WV						SWT-250AVWV
Presure(Bar)			4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5
Psig			65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152
Capaciy(m/min)			21.8-43.5	20.5-41.0	21.2~38.5	20.4~-34.0	16.0~32.0	14.7~26.8	22.8-45.5	23.9-43.5	20.3-40.5	20.9-38.0	20.1~36.5	19.8~30.5	40.8-51.0	20.5-45.5	21.5-43.0	20.3-40.5	22.8~38.0	19.2~32.0	43.1~61.5	43.2~54.0	40.0~50.0	22.5-45.0	21.5-43.0	20.9~38.0
Power(Kw)			185						200						220						250
Water Cooling	Oulet Pipe		DN100			DN100		DN80	DN100			DN100			DN125	DN100		DN100			DN125			DN100
	Weight(Kg)		5350			5200		4100	5500			5250			7000	5650		5350			7200			5400
	Dimension	L(mm)	4100			3680		3350	4100			3680			4450	4100		3680			4450			3680
		W(mm)	2150			2020		1900	2150			2020			2350	2150		2020			2350			2020
		H(mm)	2250			2350		1900	2500			2350			2350	2500		2350			2350			350
Air Cooling	Outlet Pipe		DN100					DN80	DN100						DN100	DN100					DN125			DN100
	Weight(Kg)		5500					4200	5700						7800	5900					7400			6100
	Dimension	L(mm)	4550					4250	4550						5250	4550					5250			4550
		W(mm)	2200					2060	2200						2500	2200					2500			2200
		H(mm)	2300					2150	2300						2450	2300					2450			2300

SWT-280WV~SWT-450WV

Model			SWT-280WV						SWT-300WV						SWT-355WV						SWT-400WV					SWT-450WV
Pressure(Bar)			4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	4.5	5.5	6.5	7.5	8.5	10.5	5.5	6.5	7.5	8.5	10.5	6.5	7.5	8.5	10.5
Psig			65	80	94	109	123	152	65	80	94	109	123	152	65	80	94	109	123	152	80.00	94.00	109.00	123.00	152.00	94.00	109.00	123.00	152.00
Capacity(m³min)			42.6-71.0	43.0~61.5	42.0-56.0	42.8-53.5	22.5-45.0	21.0-42.0	41.8~76.0	43.6-67.0	42.3-65.0	44.3~59.0	41.3~55.0	38.4-48.0	44.6-81.	41.8~76.	41.4-69.	42.9-66.0	42.0~60.0	41.3~55.0	44.6~81.	41.5~75.	42.0~70.0	42.9-66.0	42.0~60.0	44.6~81.0	44.6~81.	43.8~73.	41.6-64.0
Power(Kw)			280						300						355						400					450
Outlet Pipe			DN150	DN125			DN100		DN150			DN125			DN150			DN125			DN150				DN125	DN150
Weight(Kg)			7600	7400			5500		7850			7600			8100			7800			8350				8000	8600
Water Cooling	Dimension	L (mm)	4700	4450			3680		4700			4450			4700			4450			4700				4450	4700
		W (mm)	2500	2350			2020		2500			2350			2500			2350			2500				2350	2500
		H (mm)	2400	2350			2350		2400			2350			2400			2350			2400				2350	2400

SWT-45WV~SWT-160WV

Model		SWT-37WV	SWT-45WV		SWT-55WV		SWT-75WV		SWT-90WV		SWT-110WV		SWT-132WV		SWT-160WV
Pressure(Bar)		2.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5
Psig		36	36	51	36	51	36	51	36	51	36	51	36	51	36	51
Capacity(m³min)		4.2~10.5	5.4~13.5	5.3~9.7	6.8~17.1	6.9~12.5	9.2~23.0	10.2~18.5	11.4~28.5	12.5~22.8	13.8~34.5	14.9~27.0	16.4~41.0	18.7~34.0	20.4~51.0	22.3~40.5
Power(Kw)		37	45		55		75		90		110		132		160
Outlet Pipe		DN80	DN80		DN125	DN80	DN125		DN125		DN150	DN125	DN150		DN150	DN150
Weight(Kg)		2200	2350		2600	2500	2800		3000		3300	3200	3400		4000	3600
Dimension	L (mm)	2640	2640		3000	2640	3000		3000		3200	3000	3200		3550	3200
	W (mm)	1650	1600		1800	1600	1800		1800		2000	1800	2000		2000	2000
	H (mm)	1790	1750		2000	1750	2000		2000		2300	2000	2300		2000	2300

SWT-185WV~SWT-450WV

Model		SWT-185WV		SWT-200WV		SWT-220WV		SWT-250WV		SWT-300WV		SWT-355WV		SWT-400WV		SWT-450WV
Pressure(Bar)		2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5	2.5	3.5
Psig		36	51	36	51	36	51	36	51	36	51	36	51	36	51	36	51
Capacity(m³min)		24.4~61.0	23.9~43.5	26.4~66.0	26.1~47.5	28.4~71.0	31.4~57.0	32.8~82.0	35.8~65.0	39.2~98.0	38.5~70.0	47.2~118.0	45.1~82.0	52.0~130.0	47.9~87.0	58.8~147.0	53.4~97.0
Power(Kw)		185		200		220		250		300		355		400		450
Outlet Pipe		DN150	DN150	DN200	DN150	DN200	DN150	DN200		DN250	DN200	DN250	DN200	DN250		DN250
Weight(Kg)		4200	4000	5000	4200	5100	4300	5200		5000	5300	6600	5400	6700		6800
Dimension	L (mm)	3550	3350	3850	3350	3850	3550	3850		3550	3850	4600	3850	4200		4200
	W (mm)	2000	2000	2100	2000	2100	2000	2100		2000	2100	2200	2100	2200		2200
	H (mm)	2000	2300	2100	2200	2100	2000	2100		2000	2100	2250	2100	2250		2250

SWT-200WV~SWT-220WV

Model		SWT-200WV				SWT-220WV
Pressure(Bar)		6.5	7.5	8.5	10.5	6.5	7.5	8.5	10.5
Psig		94	109	123	152	94	109	123	152
Capacity(m³min)		30.8~44	29.4~42	28~40	23.8~34	33.6~48	32.2~46	30.8~44	26.6~38
Power(Kw)		200				220
Outlet Pipe		DN100				DN100
Weight(Kg)		Weight	6500KGS			Weight	6600KGS
Dimension	L (mm)	L(mm)	3760			L(mm)	3760
	W (mm)	W(mm)	2370			W(mm)	2370
	H (mm)	H(mm)	2290			H(mm)	2290

SWT-250WV

Model	SWT-250WV
Pressure		7.5	8.5	10.5
Pressure		7.5	8.5	10.5
Psig		109	123	152
Capacity (m³/min)		34.3~49	33.6~48	30.1~43
Power	250
Water Cooling	DN100
	Weight	6700KGS
	L(mm)	3760
	W(mm)	2370
	H(mm)	2290
